Description
DENALI 2.0 Installation and Operation
Housed in compact aluminum pods measuring just 2.2in in diameter and 2.4in deep the D2 LED lights are perhaps the most versatile design available; powerful enough to be your “primary” driving light yet small and light enough to comfortably mount on a fender. The DENALI D2s feature durable black powder-coated finishes and special cooling fins to make sure the LED itself runs cool and bright. New for the DENALI 2.0 series is a special Impact PC™ corrosion proof bezel that ensures your lights will continue to look great even after repeated stone and debris impacts. Low profile hinge mounts offer secure mounting and include stainless steel M8 mounting hardware for installation on light bars or model specific light mounts.
The D2 2.0 kit uses a just-developed HotSwap™ modular wiring harness that by default causes these single intensity lights to function at full brightness. But if you would like them to operate at both half and full power simply add the dual intensity DataDim™ controller. No other changes are required except to replace the original relay with the DataDim™ module and connect one wire to the high-beam circuit. (You can also purchase a three-position switch to manually control light intensity independent of the bike’s high beam.)
Also new with the DENALI 2.0 generation of lighting is the industry-leading TriOptic™ lens system. Each lamp comes with both spot (installed) and flood (supplied) lenses nothing else to buy. The spot lens produces the greatest beam distance while the flood lens produces a broader spread of light closer to the motorcycle filling the road edge and shoulders. To get the best of both worlds use a spot lens on one light and a flood lens on the other light for distance illumination and a useful spread of light at close range. The flood lenses are E-Marked to be road legal in countries where this is a requirement. No matter which lens you choose the D2 2.0 light kit lets you see the road (or lack thereof) and be seen by other traffic around you. It’s that simple: See further be seen better with DENALI!
Specifications:
- LEDs 10 Watt Cree XPL HI (per lamp)
- Power Draw: 1.6 amps (total)
- Beam Distance (spot): 525ft
- Beam Width (spot): 75ft
- Raw Lumens: 2190
- Intensity: Single Intensity Harness
- DataDim™ Compatible: Yes
- Operating Voltage: 12v
- Pod Size 2.2in diameter x 2.4in deep
D2 Kit Contents:
- (2) LED Light Pods
- (2) Spot lenses (pre-installed)
- (2) E-Mark approved elliptical flood lenses
- (1) HotSwap™ single intensity wiring harness
- (1) DrySeal™ waterproof illuminated switch
- (1) 7/8in Handlebar switch mount
- (1) 1in Handlebar switch mount
- (2) Hinge mounts with M8 stainless steel hardware
- (4) Zip ties & (1) adhesive mounting square
